DS Double-crank H-frame straight-side
1 000 – 4 000 kN
Up to 4 000 kN. Available with crank, link-drive or servo-drive packages.
DS The DS range is the new flagship straight-side press — a full H-frame architecture with two connecting rods, large bolsters and the option of three distinct drive technologies. Choose conventional crank for general progressive-die work, link-drive to reduce slide velocity around bottom dead centre for deep-draw and stretch-form applications, or servo-drive for full programmable motion profiles, energy recovery and the shortest tool-changeover cycles.
Key features
- H-frame straight-side — maximum bending and torsion rigidity.
- Two connecting rods · eight long guides.
- Bolsters up to 2 920 × 1 100 mm on the DS4000.
- Three drive variants — crank, link-drive, servo — on one mechanical platform.
- DMS with fixed-stroke or full-automatic versions available.
- Optional temperature control for thermal stability in long runs.
- Reference installations from 1 000 kN presses up to DS8000 transfer presses.
Specifications
Model designations and units as published in the 2026 catalogue. Verify the exact figure with our engineering team before quoting.
| Parameter | DS1000-E2V | DS1600-E2V | DS2500-E2V | DS4000-E2V |
|---|---|---|---|---|
| Nominal capacitykN | 1 000 | 1 600 | 2 500 | 4 000 |
| Nominal heightmm | 6.3 | 6.3 | 6.3 | 6.3 |
| Flywheel energy, continuouskJ | 6.30 | 10.08 | 15.75 | 25.20 |
| Flywheel energy, single strokekJ | 12.60 | 20.16 | 31.50 | 50.40 |
| Nominal speedspm | 58 | 47 | 35 | 37 |
| Variable speedspm | 29–75 | 23–61 | 26–45 | 19–50 |
| Stroke adjustmentmm | 160 | 200 | 250 | 315 |
| Bed dimensions (W × D)mm | 1 660 × 630 | 2 000 × 760 | 2 420 × 910 | 2 920 × 1 100 |
| Slide dimensions (W × D)mm | 1 410 × 550 | 1 700 × 660 | 2 030 × 850 | 2 450 × 1 000 |
| Shut heightmm | 350 | 410 | 470 | 550 |
| Gap between columnsmm | 650 | 780 | 720 | 1 120 / 820 |
| Height of work surfacemm | 920 | 980 | 1 060 | 1 100 |
| Slide adjustmentmm | 80 | 95 | 110 | 120 |
| Driving motorkW | 18.5 | 20 | 25 | 45 |
All DS models: 2 conrods · 8 long guides · 400 V / 50 Hz · DMS control standard. Offered in fixed-stroke (DMS), automatic, link-drive and servo configurations. The catalogue range is published as E2V (variable stroke). Specifications subject to change without prior notice.
